8K Ultra-high Resolution Video Wall Controller 1 in 6 Out Multi-Screen Expander Plug and Play

Product Categories
Shenzhen Bitvisus Technology Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

8K Ultra-high Resolution Video Wall Controller 1 in 6 Out Multi-Screen Expander Plug and Play

Brand Name : Bitvisus

Place of Origin : Guangdong, China

MOQ : 1

Price : Contact us

Model Number : BIT-MSE-8K-106Pro

Certification : CE,HDMI,HDCP,RoHS,FCC

Payment Terms : T/T,PayPal

Supply Ability : 1000

Delivery Time : 5-8 days

Packaging Details : 360mm × 215mm × 70mm

Input Interface : 1 X HDMI 2.1, 1 X DP 1.4 (Copper wire≤3M)

Output Interface : 6 X HDMI 1.4 (Copper wire≤10M)

Input Pixel Frequency : 1200MHz

Output Pixel Frequency : 330MHz

Power Supply : 12V5A

Product Dimensions : 290mm × 143mm × 35mm

Package Dimensions : 360mm × 215mm × 70mm

Net Weight : 1.2KG

Package Weight : 1.7KG

Input Resolution : 7680x4320P30

Output Resolution : 3840x2160P30, 1920x1080P120

Color Depth : 8bit

Color Format : RGB444, YUV444, YUV422, YUV420

Power Consumption : 50W

Working Temperature : 0～50ºC

Contact Now

8K Multi-Screen Expander 106Pro
Plug and Play 1 in 6 Out 2X2 3X2 Video Wall Controller for Multi-screen Display

8K Ultra-high Resolution Video Wall Controller 1 in 6 Out Multi-Screen Expander Plug and Play


Product Overview
8K Ultra-high Resolution Multi-Screen Viewer with advanced display management capabilities.
  • Support 1-way 8K input with HDMI and DP interface options for clear image quality and rich details
  • Support 4K30, 1080P60, 1200P60, 1080P120, 1200P120 output for flexible display configuration
  • Ultra-high resolution support up to 7680x4320P30 input
  • Support 1XN, NX1, MXN pixel-to-pixel splicing without stretching or deformation
  • Support EDID management with dial code selection
  • 3.5MM audio separation and HDMI audio follow out for diverse audio options
  • Support for parallel use to protect large screen real-time display requirements
  • Compatible with Bitvisus Window software for 8K multi-screen display
Welcome to contact us to consult about the products required by your project!
Key Features
8K Ultra-high Resolution Video Wall Controller 1 in 6 Out Multi-Screen Expander Plug and Play
Product Specifications
Product Name BIT-MSE-8K-106Pro
HDCP HDCP2.2
Input Interface Type HDMI2.1x1, DP1.4x1 (Copperwire ≤ 3M)
Input Maximum Resolution 2×2:7680×4320P30, 2×3:5760×2160P60/5760×2400P60, 3×2:7680×6480P20, 6×1:1920×6480P60/1920×7200P60
Output Interface Type HDMI1.4x6 (Copperwire ≤ 10M)
Output Resolution 3840×2400P30, 3840×2160P30, 1920×1200P120, 1920×1080P120, 1920×1200P60, 1920×1080P60
Audio 3.5MM audio separation, HDMI audio follow out
Power Supply 12V5A
Power Consumption 50W
Product Size LxWxH:290 mm × 143 mm × 35 mm
Net Weight 1.2KG
Accessories 1 × 220V Power cable, 1 × HDMI cable or DP cable, 1 × blue network cable, 1 × IR infrared head, 1 × remote control, 1 × USB A-B cable
Warranty 3 years warranty
Product Configuration
8K Ultra-high Resolution Video Wall Controller 1 in 6 Out Multi-Screen Expander Plug and Play
Frequently Asked Questions
Why Choose Bitvisus?
  • We have our own warehouse for fast shipping within 48 hours
  • OEM/ODM services available for custom requirements
  • Extensive product range including Video Wall Controllers, Multiscreen Expanders, Multiviewers, and Embedded Projector Fusion
Shipment & Payment
  • Payment Methods: T/T, Visa, PayPal, Western Union, L/C
  • Shipping Options: DHL, UPS, EMS, FedEx, Air freight, Sea freight
How to Order?
  • Contact us via email, TradeManager, WhatsApp, or Skype with your requirements
  • We will provide a proforma invoice based on your order
  • After payment confirmation, we will deliver your goods promptly

Product Tags:

8K Ultra-high Resolution Video Wall Controller



1 in 6 Out Multi-Screen Expander



Plug and Play HDMI Video Processor


Quality 8K Ultra-high Resolution Video Wall Controller 1 in 6 Out Multi-Screen Expander Plug and Play for sale

8K Ultra-high Resolution Video Wall Controller 1 in 6 Out Multi-Screen Expander Plug and Play Images
