4K30Hz Video Wall Controller with 100m Transmission and USB-KVM Function for Multi-Channel HDMI KVM Extender

Brand Name : Bitvisus

Place of Origin : Guangdong, China

MOQ : 1

Price : Contact us

Model Number : BIT-Ex-IP-4K-KVM

Certification : CE,HDMI,HDCP,RoHS,FCC

Payment Terms : T/T,PayPal

Supply Ability : 1000

Delivery Time : 5-8 days

Packaging Details : 105*76*27mm

Material : Metal

Input Transmitter : HDMI 1.4 (≤ 5 m), IR, RS232 signal

Output Transmitter : CAT5E / CAT6, 100m

Supported resolution : 4K30Hz

Color Space : RGB444, YUV

Pixel bandwidth : 297MHz

Transmission bandwidth : 10.2Gbps

Transmission distance : 100m

Interface Protocol : HDMI1.4, HDCP 1.4, DVI1.0, VGA

Power supply : DC 12V 2A

Power consumption : 6W

Operating temperature : -25～55ºC

Dimensions : 105*76*27mm

Weight : 0.5KG

USB Support : USB2.0, KVM function

Contact Now

HD Network Extender Multi-channel LCD Video Processor
4K60 TV Video Wall Controller with 4 HDMI Inputs Switcher and USB-KVM functionality

4K30Hz Video Wall Controller with 100m Transmission and USB-KVM Function for Multi-Channel HDMI KVM Extender
Product Overview
Advanced 4K30 USB KVM HDMI Extender featuring industry-leading video processing technology for professional applications.
Key Features
  • Ultra-high definition 4K resolution support with advanced video processing chip
  • Extended transmission distance up to 100m via HDMI interface
  • Maximum resolution support: 3840x2160@30Hz with backward compatibility
  • Bi-directional RS232 communication functionality
  • USB-KVM support with dual USB interfaces for mouse and keyboard connectivity
  • High-speed USB2.0 extension for touchscreens, storage devices, and peripherals
  • EDID Management for easy display configuration
  • Network IP transmission support with Gigabit switch compatibility
  • Zero-delay transmission with ultra-low compression and plug-and-play operation
    4K30Hz Video Wall Controller with 100m Transmission and USB-KVM Function for Multi-Channel HDMI KVM Extender
Contact our technical team today!
Welcome to consult about your project requirements and custom solutions.
Product Images
Technical Specifications
Input Transmitter (TX): HDMI 1.4 (≤ 5m), IR, RS232 signal
Output Receiver (RX): CAT5E/CAT6 (100m)
Transmission Transmitter (TX): CAT5E/CAT6 (100m)
Audio HDMI audio output
Supported Resolution 4K30Hz with backward compatibility for standard resolutions
Color Space RGB444; YUV color space
Pixel Bandwidth 297MHz
Transmission Bandwidth 1Gbps
Transmission Distance 100m
Supported Features EDID learning, CEC, 3D, Remote wake up, OEM
RS232 Two-way RS232 transparent transmission
Interface Protocol HDMI1.4, HDCP 1.4 compatible with DVI1.0, VGA
Power Supply DC 12V 2A
Power Consumption 6W
Operating Temperature -25°C to 55°C
Storage Temperature -10°C to 50°C
Dimensions & Weight 105×76×27mm, 0.5KG
4K30Hz Video Wall Controller with 100m Transmission and USB-KVM Function for Multi-Channel HDMI KVM Extender
Package Contents
Equipment ×2, power supply ×2, double-ended USB cable ×1, certificate ×1, warranty card ×1
Warranty & Support
Comprehensive 1-year warranty with lifetime technical support.
